Bird 100H 2–30 MHz 100 W Wattmeter Elements

Bird 100H 2–30 MHz 100 W Wattmeter Elements Technical Specifications

• Frequency Range: 2–30 MHz

• Power Measurement Capacity: 100 W full scale (Full Scale)

• Model Code: 100H

• Compatibility: Bird 43, Bird 4421 and other compatible Bird Thruline wattmeters can be used.

• Connection Type: Standard Bird interchangeable wattmeter element.

• Impedance: 50 Ω

• Measurement Direction: Forward power measurement on the body; reflected power measurement can be performed by reversing.

• Accuracy: Bird Typical ±5% full scale measurement accuracy with the Thruline wattmeter system.

• Application: HF communication systems, amateur radio applications, broadcast infrastructure, telecom applications and defense industry RF testing.

• Construction: Directional Coupler technology, brass housing, modular and interchangeable wattmeter element.

• Manufacturer: Bird Electronic Corporation – Cleveland, Ohio, USA.
