Philips Pm6615 8 Digit 2 Channel 10 Hz – 1 GHz Counter

Philips PM6615 8 Digit 2 Channel 10 Hz – 1 GHz Frequency Counter Technical Specifications

• Frequency Measurement Range: Channel A: 10 Hz – 80 MHz, Channel B: 50 MHz – 1 GHz

• Display: 8 digit LED digital display

• Number of Channels: 2 input channels (A and B)

• Measurement Functions: Frequency, period, pulse count (Count A) and ratio measurement (A/C or B/C)

• Connection Type: 2 BNC inputs (Channel A: 1 MΩ / 25 pF, Channel B: 50 Ω)

• Input Sensitivity: 10 mV / 200 mV selectable

• Input Coupler: AC and DC selectable (Channel A)

• Maximum Input Level: Channel A: 220 V maximum, Channel B: 10 mV – 12 V maximum

• AGC Feature: Automatic gain control (AGC) for high frequency input from 50 MHz to 1 GHz

• Dimensions & Weight: Approximately 250 × 110 × 300 mm, approximately 3.5 kg

• Key Technical Advantages: 8-digit LED display, frequency measurement up to 1 GHz, dual-channel input architecture, selectable input sensitivity, high-frequency input with AGC support, and frequency/period measurement functions.
